Eco-Centric Pulp Mold Coating Machine for Bio-Based Coating Application on Straw and Bamboo Fiber Products
제품 상세 정보:
| 원래 장소: | 중국 |
| 브랜드 이름: | OSMANUV |
| 인증: | CE |
| 모델 번호: | OSM-SXT-450T |
| 문서: | CE-Single station spin caot...ne.pdf |
결제 및 배송 조건:
| 최소 주문 수량: | 1 세트 |
|---|---|
| 가격: | negotiable |
| 포장 세부 사항: | 목재 포장 |
| 배달 시간: | 30 일 |
| 지불 조건: | t/t |
| 공급 능력: | 협상 |
|
상세 정보 |
|||
| 제품 이름: | 단역 스핀 코팅 기계 | 사양: | 700mm l*420mm W*1135mm h |
|---|---|---|---|
| 무게: | 순 중량 : 120kg; 총 체중 : 130kg | 전압: | 380V 50Hz |
| 힘: | 500 Ｗ | 스핀 속도: | 1150 RPM (최대 속도) |
| 보증: | 1 년 | ||
제품 설명
Eco-Centric Pulp Mold Coating Machine for Bio-Based Coating Application on Straw and Bamboo Fiber Products
Product Description
This eco-centric single-station coating machine is specifically designed for applying bio-based coatings to sustainable pulp molds from straw, bamboo, and sugarcane bagasse. It supports the production of 100% compostable and biodegradable packaging by ensuring an even, effective barrier layer without compromising environmental credentials. The system is highly customizable for various bio-coating viscosities and curing requirements.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model | OSM-SXT-450T |
| Power Supply | 380V/50Hz |
| Power Consumption | 2.2 kW (Energy Efficient) |
| Heating Option | Customizable IR pre-drying module available |
| Coating Capacity | 100-400 pieces/hour |
| Rotation Speed Range | 50-1200 RPM (optimized for bio-coatings) |
| Control System | Microprocessor with simple interface |
| Coating Reservoir | Easy-clean, corrosion-resistant tank |
| Dimensions (LxWxH) | 1400mm x 1200mm x 1500mm |
Application
-
Perfect for applying PLA or other bio-polymer coatings to straw and bamboo pulp-based products.
-
Coating for fully compostable sugarcane bagasse tableware requiring certified coatings.
Feature
-
Bio-Coating Optimized: Designed for the specific flow characteristics of bio-based coatings.
-
Easy Cleaning: Simplified design with minimal parts for quick and easy cleaning between batches.
-
Low Energy Consumption: Focuses on reducing the overall carbon footprint of the coating process.
-
GreenTech Compliance: Ideal for manufacturers aiming for BPI or OK Compost INDUSTRIAL certifications.
Customization
Key customizable features include:
-
Drying Integration: Can be customized with integrated IR or hot air modules for in-line pre-drying.
-
Material Compatibility: Adjustable parameters for different bio-coating types and viscosities.
-
Safety Features: Enhanced safety interlocks can be added as per request.
Support and Services
Dedicated support for sustainable packaging producers, including assistance with coating selection and process optimization for bio-materials.
Packing and Shipping
All components are packed with recyclable and biodegradable materials where possible, aligned with our commitment to sustainability.
FAQ
-
Q: Can this machine handle PLA coatings effectively?
-
A: Absolutely. The rotation speed and application process are customizable to handle the specific viscosity and drying behavior of PLA coatings.
-
-
Q: Is the machine suitable for a lab or R&D setting?
-
A: Yes, its small footprint and programmable recipes make it ideal for both R&D and small-batch production.
-
